Scaffolding Framework

Scaffolding Standard offers the best value for money.

What are the properties of BS EN 39 scaffold tube, and how is its weight calculated?

Scaffold tube to BS EN 39:2001 in grade S235GT has a yield strength of 235, tensile strength of 340-520 and elongation of 24%. The outside diameter is 48.3 mm, with a wall thickness of 3.2 or 4.0 mm (weighing 3.56 and 4.37 kg/m respectively). To get the weight per piece, use this formula:

(OD - thickness) x thickness x 0.02466 x length = weight per piece (kg)

Permitted tolerances: outside diameter +0.5 mm, thickness -10%, weight -7.5%.

What sizes do steel scaffold planks come in?

Galvanized steel scaffold planks (metal planks) follow EN1004:2004 and BS EN12811-1:2003, with a thickness of 1.1-2.0 mm and lengths of 1,000-4,000 mm. Their cross-section carries load well, and they are easy to install, strip and store, and easy to count.
